LP Series

Items

Characteristics

Category Temperature Range

-40 to  85 VII (6.3 to 10OVdc) -25 to 85 dagger (160 to 450Vdc)

Rated Voltage Range

6.3to450Vdc

Capacitance Tolerance

± 20%(M) (at20℃,120Hz)

Leakage Current

l=0.02CV or 3mA, whichever is smaller.

Where, I: Max. leakage Currency(μA) C : Npminal capacitance(μF), V: Rated voltage (V)(at20℃ after 5 Miutes)

Dissipation Factor (tanδ)

Rated voltage (Vdc)

6.3V

10V

16V

25V

35V

50V

63V

80V

100 V

160 to 250V

315 to 400V

450V

tanδ (Max.)

0.6

0.6

0.4

0.35

0.3

0.25

0.2

0.15

0.15

0.15

0.15

0.15

*:0.15 forΦD=35mm

(at20tC,120Hz)

Low Temperature Characteristics (Max. Impedance Ratio)

Rated voltage (Vdc)

6.3V

10V

16V

25V

35V

50V

63V

80V

100 V

160 to 250V

315 to 400V

450V

(at 120Hz)

Z(- 25℃)

Z( 20℃)

4

4

4

3

3

2

2

2

2

4

4

8

Z(-40 ℃ ）Z( 20 ℃)

15

15

15

10

8

6

6

5

5

—

—

—

The following specifications shall be satisfied when the capacitors are restored to20℃ after exposing them for 1000 hours at 85℃

witheut voltage applied.

The following specifications shall be satisfied when the capacitors are restored to20 C after exposing them for 1000 hours at 85℃

witheut voltage applied.
